LT1217 - Low Power 10MHz Current Feedback Amplifier

LT1217 - Low Power 10MHz Current Feedback Amplifier - Linear Technology（凌力尔特）

功能描述

The LT1217 is a 10MHz current feedback amplifier with DC characteristics better than many voltage feedback amplifiers. This versatile amplifier is fast, 280ns settling to 0.1% for a 10V step thanks to its 500V/µs slew rate.The LT1217 is manufactured on Linear Technology’s proprietary complementary bipolar process resulting in a low 1mA quiescent current. To reduce power dissipation further, the LT1217 can be turned off, eliminating the load current and dropping the supply current to 350µA.The LT1217 is excellent for driving cables and other low impedance loads thanks to a minimum output drive current of 50mA. Operating on any supplies from ±5V to ±15V allows the LT1217 to be used in almost any system. Like other current feedback amplifiers, the LT1217 has high gain bandwidth at high gains.The bandwidth is over 1MHz at a gain of 100.The LT1217 comes in the industry standard pinout and can upgrade the performance of many older products.

特点

1mA Quiescent Current

50mA Output Current (Minimum)

10MHz Bandwidth

500V/µs Slew Rate

280ns Settling Time to 0.1%

Wide Supply Range, ±5V to ±15V

1mV Input Offset Voltage

100nA Input Bias Current

100M ohms Input Resistance

应用

Video Amplifiers
