LT1012 - Picoamp Input Current, Microvolt Offset, Low Noise Op Amp

LT1012 - Picoamp Input Current, Microvolt Offset, Low Noise Op Amp - Linear Technology（凌力尔特）

功能描述

The LT1012 is an internally compensated universal precision operational amplifier which can be used in practically all precision applications. The LT1012 combines picoampere bias currents (which are maintained over the full –55°C to 125°C temperature range), microvolt offset voltage (and low drift with time and temperature), low voltage and current noise, and low power dissipation. The LT1012 achieves precision operation on two Ni-Cad batteries with 1mW of power dissipation. Extremely high common mode and power supply rejection ratios, practically unmeasurable warm-up drift, and the ability to deliver 5mA load current with a voltage gain of one million round out the LT1012’s superb precision specifications.

The all around excellence of the LT1012 eliminates the necessity of the time consuming error analysis procedure of precision system design in many applications; the LT1012 can be stocked as the universal internally compensated precision op amp.

特点

OP-07 Type Performance:at 1/8th of OP-07’s Supply Currentat 1/20th of OP-07’s Bias and Offset Currents

Guaranteed Offset Voltage: 25µV Max

Guaranteed Bias Current: 100pA Max

Guaranteed Drift: 0.6µV/°C Max

Low Noise, 0.1Hz to 10Hz: 0.5µVP-P

Guaranteed Low Supply Current: 500µA Max

Guaranteed CMRR: 114dB Min

Guaranteed PSRR: 114dB Min

Guaranteed Operation at ±1.2V Supplies

应用

Replaces OP-07 While Saving Power

Precision Instrumentation

Charge Integrators

Wide Dynamic Range Logarithmic Amplifiers

Light Meters

Low Frequency Active Filters

Thermocouple Amplifiers

以下列出了不同封装及包装形式的具体型号,并标出了直接在linear官网上订货的价格（美元）

器件型号	封装	温度	价格 (以 1 ~ 99 片为批量)	价格 (以 1000 片为批量)
LT1012ACN8	N-8	C	$4.75	$3.85
LT1012ACN8#PBF	N-8	C	$4.75	$3.85
LT1012ACS8	SO-8	C	$5.09	$3.85
LT1012ACS8#PBF	SO-8	C	$5.09	$3.85
LT1012ACS8#TR	SO-8	C		$3.91
LT1012ACS8#TRPBF	SO-8	C		$3.91
LT1012AIN8	N-8	I	$5.63	$4.25
LT1012AIN8#PBF	N-8	I	$5.63	$4.25
LT1012AIS8	SO-8	I	$5.63	$4.25
LT1012AIS8#PBF	SO-8	I	$5.63	$4.25
LT1012AIS8#TR	SO-8	I		$4.31
LT1012AIS8#TRPBF	SO-8	I		$4.31
LT1012CN8	N-8	C	$3.33	$2.65
LT1012CN8#PBF	N-8	C	$3.33	$2.65
LT1012DN8	N-8	C	$2.00	$1.60
LT1012DN8#PBF	N-8	C	$2.00	$1.60
LT1012IN8	N-8	I	$4.42	$3.55
LT1012IN8#PBF	N-8	I	$4.42	$3.55
LT1012IS8	SO-8	I	$4.73	$3.65
LT1012IS8#PBF	SO-8	I	$4.73	$3.65
LT1012IS8#TR	SO-8	I		$3.71
LT1012IS8#TRPBF	SO-8	I		$3.71
LT1012S8	SO-8	C	$4.00	$3.30
LT1012S8#PBF	SO-8	C	$4.00	$3.30
LT1012S8#TR	SO-8	C		$3.36
LT1012S8#TRPBF	SO-8	C		$3.36
