LTC1044S8 - LTC1044S8是Switched Capacitor Voltage Converter

LTC1044S8是LINEAR凌力尔特公司的一款未调整的倍压 / 负输出充电泵产品，LTC1044S8是LTC1044S8是Switched Capacitor Voltage Converter，本站介绍了LTC1044S8的封装应用图解、特点和优点、功能等，并给出了与LTC1044S8相关的LINEAR元器件型号供参考。

LTC1044S8 - LTC1044S8是Switched Capacitor Voltage Converter - 未调整的倍压 / 负输出充电泵 - 电源管理 - 凌力尔特

LTC1044S8 - Switched Capacitor Voltage Converter

LTC1044S8 - Switched Capacitor Voltage Converter - Linear Technology（凌力尔特）

功能描述

The LTC1044 is a monolithic CMOS switched capacitor voltage converter which is manufactured using Linear Technology's enhanced LTCMOSTM silicon gate process. The LTC1044 provides several voltage conversion functions: the input voltage can be inverted (VOUT=-VIN), doubled (VOUT=2 VIN), divided (VOUT=VIN/2) ormultiplied (VOUT=?nVIN).Designed to be pin-for-pin and functionally compatible with the popular 7660, the LTC1044 provides significant features and improvements over earlier 7660 designs. These improvements include: full 1.5V to 9V supply operation over the entire operating temperature range, without the need for external protectiondiodes; 21/2 times lower quiescent current for greater power conversionefficiency; and a "boost" function which is available to raise the internaloscillator frequency to optimize performance in specific applications.Although the LTC1044 provides significant design and performance advantages over the earlier 7660 device, it still maintains its still maintains its compatibility with existing 7660 designs.

特点

Plug-In Compatible with 7660 with These Additional Features:

Guaranteed Operation to 9V, with No External Diode, Over Full Temperature Range

Boost Pin (Pin 1) for Higher Switching Frequency

Lower Quiescent Power

Efficient Voltage Doubler

200µA Max. No Load Supply Current at 5V

97% Min. Open Circuit Voltage Conversion Efficiency

95% Min. Power Conversion Efficiency

Wide Operating Supply Voltage Range, 1.5V to 9V

Easy to Use

Commercial Device Guaranteed Over -40°C to 85°C Temperature Range
